Screen Printing on Glass Border

Automatic Glass Screen Printing Machine

Digital printing of water-based inks on the surface of aluminum sheet

The automatic glass screen printing machine is an industrial-grade device specifically designed for printing single-color or multi-color borders on the edges or specified areas of glass. It utilizes screen printing technology, combined with automated control systems and precision mechanical design. The primary function of the machine is to transfer ink through a screen onto the glass surface, forming a high-adhesion, weather-resistant decorative or functional coating. This solution is particularly effective for large-scale, high-repeatability, standardized production, widely used in architectural facades, home appliance panels, and electronic screens.

Max. resolution 2160 dpi
Max. printing area 3300×9000mm
Printing speed up to 70 m²/h

Technical Specifications

Model	DXPG2538/DXPG2550/DXPG3060/DXPG3390
Printhead brand	Xaar
Printhead quantity	4/8/12
Max. resolution	2160 dpi
Max. printing speed	70 m²/h
Max. printing area	2500×3800/2500×5000/3000×6000/3300×9000mm
Material thickness	0-50mm
Ink type	eco-friendly ceramic inks
Ink color	black/white (single color printing), black (border printing)
Input format	PDF, JPEG, TIFF, EPS, AI
Power consumption	20-35 kW
Electrical requirement	Configurable according to local voltage and frequency requirements.
Environmental requirement	Independent, clean, dust-free, low light exposure, and well-ventilated.
Ambient temperature	22℃ to 28℃(72℉ to 82℉)
Relative humidity	40%-70% (non-condensing)

Main Features

Precision Screen Printing System
1. High-Resolution Printing: Achieves up to 2160 dpi resolution for sharp and vibrant borders.
2. Multi-Color Capability: Supports both single-color and multi-color printing options, offering flexibility for various design requirements.
3. Accurate Ink Transfer: Advanced screen mesh technology ensures even ink distribution without streaks or blurs.
Automation and Efficiency
1. High-Speed Production: Capable of printing up to 70 m²/h, ideal for high-volume manufacturing.
2. Automatic Alignment and Registration: Reduces manual intervention, ensuring consistent quality across each print cycle.
3. Continuous Feed System: Allows seamless processing of multiple glass sheets for uninterrupted production.
Durability and Weather Resistance
1. Long-Lasting Coating: Printed borders are highly durable and weather-resistant, making them suitable for exterior applications.
2. Scratch and UV Resistant: Ensures longevity and maintains visual quality even under harsh environmental conditions.

Applications

Architectural Facades: Durable decorative borders for window panels and curtain walls.
Home Appliance Panels: Precision-printed borders for oven doors, refrigerators, and washing machines.
Electronic Screens: High-definition borders for touch screens, LCD displays, and control panels.
